220V 40A/63A Adjustable Voltage Relay with Over Under Voltage Protection Over Current Limit Precision Wattmeter Energy Meter with Automatic Recovery Ideal for Power Consumption Monitoring

Compatibility

To confirm that this part fits your vehicle, please enter your vehicle's details below.

• Select
• Make:
• Select
• Submodel:
• Select
• Engine:

This part is compatible with vehicle(s).Show all compatible vehicles 1

• Year
• Make
• Model
• Submodel
• Trim
• Engine

This device includes over voltage protection, ensuring that your electronics are safe from power spikes.

Under-voltage protection is also provided to prevent possible damages to your equipment during power sags.

With the over-current protection function, this wattmeter safeguards against high current that could potentially cause damage.

Featuring an automatic recovery system, the device restores normal operation after a temporary fault condition without manual intervention.

The wattmeter boasts precision in measurement, clearly displaying voltage and current figures as well as power consumption.



Rated Supply Voltage: AC 220V

Operating Voltage: AC 80-400V(single phase)

Rated Frequency: 50/60Hz

Current (>A) setting range: 1-40/63A OFF

Overvoltage (>U) setting range: 230-300V/OFF

Undervoltage (<U) setting range: 210-140V/OFF

Kilowatt-hour Protection Value: 1-9999/OFF

Output Contact: 1NO

Operating Temperature: -50℃-55℃

Humidity: ≤50% at 40℃ (without condensation)

Storage Temperature: -30℃-70℃



1 x Adjust Voltage Relay
