616  automatically recognizes and measures according to the different input voltage/current/resistance/etc. signals.

616  also has additional convenient functions of flashlight test.

Function	Range	Resolution	Accuracy
AC voltage	0~600V	0.1mV~1V	±(1.5%+8d)
DC voltage	0~600V	0.1mV~1V	±(1.2%+5d)
AC current	0~10A	0.1mA~10mA	±(2.5%+8d)
DC current	0~10A	0.1mA~10mA	±(2.2%+8d)
Capacitance	6nF~60mF	1pF~10μF	±(10%+8d)
Resistance	0~60MΩ	0.1Ω~10kΩ	±(1.5%+10d)
Hz	0~10MHz		±(4.0%+10d)
NCV induction	√	Live Zero Fire	√
Diode/On/Off	√	flashlight	√
Real-time temp	√	data retention	√
battery model	AAA*2	bright screen	√
product material	ABS	wire material	PVC/Brass
max display	6000 counts	total wire length	100cm/39.37in
Auto shut-down	√

Packing List:
1 * Digital Multimeter

1 * English user Manual

1*  Storage bag

1 * Packing box
