Mobula7 1S HD version is a light and efficiency 75mm brushless whoop which provide 1080P HD video record function. A highly integrated AIO Flight Controller, supports ESC with a maximum current output of 12A. We added blackbox for this 1s 75mm HD recorder whoop. Now it could support gyroflow. Although the external blackbox is not install perfectly and insert SD card is not friendly to most of the people, however we still think it's really excited for this small whoop could record a video with gyroflow steady and keep safe flying .

VTX Power up to 400mw

NEW RS0802 KV20000 motors

Blackbox Ready support GYROFLOW

Compatible for 1S Lipo/LIHV

Specifications:
Brand Name: Happymodel

Wheelbase: 75mm

Weight: 33g

	Configu-ration:9N12P Stator Length:2mm Motor Dimension(Dia.Len):Φ10.5mm13.5mm No.of Cells(Lipo):1S only
	Material:PC Props Dia:40mm Center Hole Dia:1.5mm
	X12 Frsky V1.0 flight controller built-in SPI Frsky 2.4G receiver Target: CRAZYBEEF4FR Sensor: ICM20689(SPI connection) Power supply: 1S battery input (DC 2.9V-4.35V) Built-in Betaflight OSD(SPI Control) Built-in ExpressLRS 2.4G,Frsky D8/D16 Built-in current sensor
	Power supply: 1S LiPo/LiPo HV Support BLHeliSuite programmable Default protocol: DSHOT300
	Packet Rate option: 50Hz/150Hz/250Hz/500Hz RF Frequency: 2.4GHz Telemetry output Power: <12dBm Couldn’t flash separately ExpressLRS firmware
Onboard Frsky SPI D8/D16 receiver Version	Packet Rate option: 50Hz/150Hz/250Hz/500Hz RF Frequency: 2.4GHz Telemetry output Power: <12dBm Couldn’t flash separately ExpressLRS firmware
Onboard 5.8g OPENVTX	Smartaudio v2.1 RCE Mode support Transmitting Power: 0/RCE/25mw/100mw/400mw Current (5v): <650ma (400mw)
	Model: RunCam Split3-Lite Video Resolution:1080@60fps/1080@50fps/1080@30fps/720@60fps Image Resolution:2 MP Interface: JST 1.25mm / UART and SH 1.0mm Hole Distance of Installation: 25.525.5mm Lens Module Size: 1414mm Power Input: DC 5-20V(Non-direct power supply from battery. Powered directly with battery will generate surges and burn the camera.)
External Blackbox	Notes:

Package Included:

Happymodel Mobula7 1S HD 75mm Micro Whoop FPV Racing Drone ELRS BNF w/ 0802 20000KV Motor RunCam Split3-Lite 1080P Camera DVR COD
