Pneumatic 4-12mm OD PU Air Tubing Pipe Hose PU Air Hose Tube Air Compressor Hose for Air Line Tubing or Fluid Transfer Tubing COD

Compatibility

To confirm that this part fits your vehicle, please enter your vehicle's details below.

• Select
• Make:
• Select
• Submodel:
• Select
• Engine:

This part is compatible with vehicle(s).Show all compatible vehicles 1

• Year
• Make
• Model
• Submodel
• Trim
• Engine

Decription:
 Pneumatic 4-12mm OD PU Air Tubing Pipe Hose PU Air Hose Tube Air Compressor Hose for Air Line Tubing or Fluid Transfer Tubing

Model number	E68448
Material	Polyurethane pneumatic tube
Color	Transparent

	Length	Outer Diameter	Inner Diameter	Min. Bending Radius	Working Pressure	Breaking Pressure
1#	160m	4mm	2.5mm	10mm	12kgf/cm²	38
2#	160m	6mm	4mm	15mm	12kgf/cm²	31
3#	80m	8mm	5mm	25mm	10kgf/cm²	32
4#	80m	10mm	6.5mm	30mm	10kgf/cm²	31
5#	80m	12mm	8mm	35mm	9kgf/cm²	27

2.  Safe, explosion-proof and pressure-resistant with high concentricity and thick pipe wall.

3. With high transparency, the flow state of the medium is clearly visible.

4. High elasticity makes the pneumatic tube have a small bending radius and is easier to install.

5. Tolerance is controlled within ± 0.05mm.

6. Suitable for various environments, carpentry, auto repair, garden irrigation, automated production, ships.

 Package Include:

1 Pack

Air hose
