Brand:
Frame
Master 5 V2
Arms
5mm
wheelbase
226mm
Micro contoller
STM32F722
IMU
BMI270
Bluetooth BLE
Supported, for flight controller configuration
OSD chip
AT7456E
ESC
50A 41N1 BL32 4-6S ESC
Motor
2306-1900KV (6S)
LED
Underneath and side
Blackbox
500MB onboard memory(Type: SD_CARD)
Propellers
1 set of GEMFAN 51466 (Notice: 5.1”)
Buzzer
TMB12A05
Power input
6S Lipo 25.2V (recommended: 1050mAh - 1500mAh)
Receiver
TBS Nano
ELRS (Default Firmware out of factory: HappyModel_EP_2400_RX V3.0.1 version)
PNP (4-pin connector reserved)
DJI O3 HD Version
Analog Version
HD Recording
Up to 4K 120fps
N/A.(Support external HD recording camera)
VTX
DJI O3 Air Unit
SpeedyBee TX800
Camera
Camera of DJI O3 System
RunCam Phoenix2 SE
Weight (without battery)
420g (±10g)
410g (±10g)
Features:
Package Included:
